| 鏈號 | 鏈號 | 節距 | 滾子直徑 | 內節內寬 | 銷軸直徑 | 銷軸長度 | 內鏈板高度 | 鏈板厚度 | 排距 | 極限拉伸載荷 | 平均拉伸載荷 | 每米長重 | |
| P | d1(max) | b1(min) | d2(max) | L(max) | Lc(max) | h2(max) | T(max) | Pt | Q(min) | Q0 | q | ||
| mm | mm | mm | mm | mmm | mm | mm | mm | mm | kN | kN | kg/m | ||
| *04CSS-2 | *25SS-2 | 6.350 | 3.30 | 3.18 | 2.31 | 14.5 | 15.0 | 6.00 | 0.80 | 6.40 | 4.20 | 5.16 | 0.28 |
| *06CSS-2 | *35SS-2 | 9.525 | 5.08 | 4.77 | 3.58 | 22.5 | 23.3 | 9.00 | 1.30 | 10.13 | 9.48 | 11.82 | 0.63 |
| 085SS-2 | 41SS-2 | 12.700 | 7.77 | 6.25 | 3.58 | 25.7 | 26.9 | 9.91 | 1.30 | 11.95 | 8.00 | 10.14 | 0.81 |
| 08ASS-2 | 40SS-2 | 12.700 | 7.95 | 7.85 | 3.96 | 31.0 | 32.2 | 12.00 | 1.50 | 14.38 | 16.92 | 21.54 | 1.12 |
| 10ASS-2 | 50SS-2 | 15.875 | 10.16 | 9.40 | 5.08 | 38.9 | 40.4 | 15.09 | 2.03 | 18.11 | 26.46 | 34.86 | 2.00 |
| 12ASS-2 | 60SS-2 | 19.050 | 11.91 | 12.57 | 5.94 | 48.8 | 50.5 | 18.00 | 2.42 | 22.78 | 38.16 | 49.26 | 2.92 |
| 16ASS-2 | 80SS-2 | 25.400 | 15.88 | 15.75 | 7.92 | 62.7 | 64.3 | 24.00 | 3.25 | 29.29 | 68.04 | 85.08 | 5.15 |
| 20ASS-2 | 100SS-2 | 31.750 | 19.05 | 18.90 | 9.53 | 76.4 | 80.5 | 30.00 | 4.00 | 35.76 | 106.20 | 131.64 | 7.80 |
| 24ASS-2 | 120SS-2 | 38.100 | 22.23 | 25.22 | 11.10 | 95.8 | 99.7 | 35.70 | 4.80 | 45.44 | 152.40 | 188.94 | 11.70 |
| 28ASS-2 | 140SS-2 | 44.450 | 25.40 | 25.22 | 12.70 | 103.3 | 107.9 | 41.00 | 5.60 | 48.87 | 206.88 | 256.50 | 15.14 |
| 32ASS-2 | 160SS-2 | 50.800 | 28.58 | 31.55 | 14.27 | 123.3 | 128.1 | 47.80 | 6.40 | 58.55 | 272.16 | 337.44 | 20.14 |
| 36ASS-2 | 180SS-2 | 57.150 | 35.71 | 35.48 | 17.46 | 138.6 | 144.4 | 53.60 | 7.20 | 65.84 | 336.30 | 417.00 | 29.22 |
| 40ASS-2 | 200SS-2 | 63.500 | 39.68 | 37.85 | 19.85 | 151.9 | 158.8 | 60.00 | 8.00 | 71.55 | 424.56 | 526.44 | 32.24 |
| 48ASS-2 | 240SS-2 | 76.200 | 47.63 | 47.35 | 23.81 | 183.4 | 190.8 | 72.39 | 9.50 | 87.83 | 612.36 | 753.18 | 45.23 |
